LUTZE silflex cable, 7 x 6mm Sq.

Add to Wishlist
Current Stock:
SKU: 100470
Shipping Cost: €8.20 (Fixed Shipping Cost)



• Machine tools and apparatus construction, transport and conveying technology, heating and cooling technology

• In dry and damp rooms

• As a control and measurement cable for medium requirements

• For flexible application without forced guidance Features

• PVC flame retardant, self-extinguishing

• Very high stability to oils, greases, acids and alkaline products

• Free from corrosive varnish (without LABS), RoHS compliant Specifications Construction

• Electrolytic bare copper conductor, thin wires according to DIN VDE 0295 class 5, IEC 60228 class 5

• Insulation of special PVC conductors

• Colour conductors according to DIN VDE 0293-308 (new) 2 conductors: brown, blue 3 conductors: green / yellow, brown, blue 4 conductors: green / yellow, brown, black, gray 5 conductors: green / yellow, blue, brown, black, Gray

• Grounding green / yellow according to DIN EN 50334 in outer layer G = with green / yellow protective conductor; × = without protective conductor

• Conductors wired in layers

• Rough PVC non-stick sleeving TM2 according to HD21.1

• Colour of the sheath Gray RAL 7001 Rated voltage U0 / U 300/500 V Test voltage 3000 V Resistance of minimum insulation 20 MΩ × km Temperature range in motion -5 ° C to +70 ° C fixation -30 ° C to +80 ° C Minimum bending radius according to VDE 0298 table 6 Flame behaviour Non-flammable according to VDE 0482 Part 265- 2; DIN EN 50265-2; IEC 60332-1 Special version K = cold resistance -30 ° C to +70 ° C T = heat resistance 0 ° C to +90 ° C
